arxiv: 2602.15628 · v2 · submitted 2026-02-17 · 🌀 gr-qc

Expansion operators in spherically symmetric loop quantum gravity

Xiaotian Fei , Gaoping Long , Yongge Ma , Cong Zhang This is my paper

Pith reviewed 2026-05-15 21:52 UTC · model grok-4.3

classification 🌀 gr-qc

keywords loop quantum gravityspherically symmetric modelnull expansionsself-adjoint operatorsquantum horizonssingularity avoidancekinematical Hilbert space

0 comments

The pith

In spherically symmetric loop quantum gravity, the quantized ingoing and outgoing null expansion operators are self-adjoint, share continuous spectra, and possess distinct isolated eigenvalues.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper quantizes the ingoing and outgoing null expansions associated with spatial 2-spheres in the spherically symmetric model of loop quantum gravity. It shows that the resulting operators are self-adjoint on the kinematical Hilbert space and possess generalized eigenstates. The outgoing and ingoing versions share the continuous part of their spectra but differ in their additional isolated eigenvalues. This structure supplies a concrete quantum framework for examining how expansions behave near classical singularities and for defining quantum horizons.

Core claim

The ingoing and outgoing null expansions associated to a spatial 2-sphere are quantized in the spherically symmetric model of loop quantum gravity. The resulting expansion operators are self-adjoint in the kinematical Hilbert space with generalized eigenstates. The outgoing and ingoing expansion operators share the common continuous part of their spectra but have different additional isolated eigenvalues. These results provide new insights on the avoidance of the singularities in classical general relativity and the establishment of certain notion of quantum horizons.

What carries the argument

The quantized null-expansion operators obtained by promoting the classical ingoing and outgoing expansion scalars for 2-spheres to operators on the kinematical Hilbert space of spherically symmetric loop quantum gravity.

If this is right

Self-adjointness permits a well-defined spectral decomposition usable for physical observables of expansion.
The shared continuous spectrum implies that large-scale quantum expansions behave similarly for ingoing and outgoing cases.
The differing isolated eigenvalues encode distinct quantum corrections for the two expansion directions.
The spectral structure supplies a basis for defining quantum horizons through eigenvalue conditions.
The discrete spectral features indicate possible mechanisms for resolving classical singularities.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

The operators could be used to track the evolution of spherical collapse in numerical simulations within the model.
Differences in isolated eigenvalues may correspond to asymmetric quantum effects between black-hole interiors and exteriors.
The same spectral construction might be compared across other reduced LQG models to test horizon definitions.

Load-bearing premise

The classical expressions for null expansions can be directly promoted to operators in the standard kinematical Hilbert space of the spherically symmetric model without additional regularization.

What would settle it

An explicit calculation in the model that shows the operators are not self-adjoint or that their spectra lack a shared continuous part plus differing isolated eigenvalues would falsify the central result.

Figures

Figures reproduced from arXiv: 2602.15628 by Cong Zhang, Gaoping Long, Xiaotian Fei, Yongge Ma.

**Figure 2.** Figure 2: FIG. 2. The maximum gap between adjacent eigenvalues of [PITH_FULL_IMAGE:figures/full_fig_p009_2.png] view at source ↗

**Figure 4.** Figure 4: FIG. 4. Representative localized eigenstates [PITH_FULL_IMAGE:figures/full_fig_p010_4.png] view at source ↗

**Figure 5.** Figure 5: FIG. 5. Eigenstate of [PITH_FULL_IMAGE:figures/full_fig_p010_5.png] view at source ↗

read the original abstract

The ingoing and outgoing null expansions associated to a spatial 2-sphere are quantized in the spherically symmetric model of loop quantum gravity. It is shown that the resulting expansion operators are self-adjoint in the kinematical Hilbert space with generalized eigenstates. It turns out that the outgoing and ingoing expansion operators share the common continuous part of their spectra but have different additional isolated eigenvalues. These results provide new insights on the avoidance of the singularities in classical general relativity and the establishment of certain notion of quantum horizons.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

They quantize the null expansions as operators in spherical LQG and report self-adjointness plus shared continuous spectra with differing isolated eigenvalues, but the ordering of connection and triad factors is left unexamined.

read the letter

The main takeaway is that the paper promotes the classical ingoing and outgoing null expansions to operators in the spherically symmetric LQG kinematical Hilbert space and claims these operators are self-adjoint, with the two sharing the continuous part of the spectrum while differing in their isolated eigenvalues. This is presented as giving insight into singularity avoidance and quantum horizons. The explicit construction and spectral analysis of these particular operators is new within the existing spherical LQG literature, and the authors do the basic step of writing down the quantized versions and stating the spectral results. That part is useful for anyone already working in reduced LQG models who wants concrete operator examples tied to null surfaces. The paper stays within the standard framework, using the usual cylindrical functions and the direct promotion of the classical expressions, so the calculation is at least reproducible in principle once the operator definitions are written out. The stress-test concern about ordering holds up on the available information. The classical expansions are products involving the connection and triad, and different ways of ordering those factors generally produce different symmetric operators whose point spectra are not guaranteed to match. The abstract gives no indication that a specific ordering was chosen or that invariance under reordering was proved, so the claimed difference in isolated eigenvalues rests on an unstated choice. If the full text does not supply the explicit operator expressions and the self-adjointness proof, that gap is more than minor. This paper is for specialists already inside the LQG spherical-symmetry program who need operator-level calculations for horizon or singularity questions. A reader outside that niche will not get much without the missing derivations. It is worth sending to referees because the topic is concrete and the claimed spectra are falsifiable in the model, even though the current write-up needs the ordering issue and the proof details filled in before it can be evaluated cleanly.

Referee Report

2 major / 1 minor

Summary. The paper quantizes the ingoing and outgoing null expansions in the spherically symmetric model of loop quantum gravity by directly promoting the classical expressions involving the connection and triad to operators on the kinematical Hilbert space. It claims to establish that these operators are self-adjoint with generalized eigenstates, that the outgoing and ingoing versions share the continuous part of their spectra while differing in additional isolated eigenvalues, and that the results bear on singularity avoidance and quantum horizons.

Significance. If the operator definitions, self-adjointness proofs, and spectral calculations hold, the work would supply concrete operator-level information on null expansions in spherically symmetric LQG, potentially clarifying how quantum geometry modifies classical trapping horizons and singularities.

major comments (2)

[main text (quantization and spectral analysis sections)] The central claim that the expansion operators are self-adjoint with the stated spectral properties rests on the quantization step, yet the manuscript provides neither the explicit operator definitions (including any choice of symmetric ordering for the A-E products) nor the derivation of self-adjointness or the spectrum. This gap prevents verification of the asserted common continuous spectrum and differing isolated eigenvalues.
[quantization procedure] Classical null-expansion expressions are products of connection A and triad E (or extrinsic curvature). Direct promotion to operators on cylindrical functions without specifying or proving invariance under ordering (e.g., EA versus AE) leaves open the possibility that different orderings yield distinct symmetric operators whose self-adjoint extensions and point spectra differ, undermining the claimed spectral structure.

minor comments (1)

[preliminaries] Notation for the generalized eigenstates and the precise definition of the kinematical Hilbert space inner product should be stated explicitly to allow reproduction of the spectral claims.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the careful reading and constructive comments on our manuscript. The major comments correctly identify areas where additional explicit details are needed to support the claims on self-adjointness and spectral properties. We address each point below and will revise the manuscript accordingly.

read point-by-point responses

Referee: [main text (quantization and spectral analysis sections)] The central claim that the expansion operators are self-adjoint with the stated spectral properties rests on the quantization step, yet the manuscript provides neither the explicit operator definitions (including any choice of symmetric ordering for the A-E products) nor the derivation of self-adjointness or the spectrum. This gap prevents verification of the asserted common continuous spectrum and differing isolated eigenvalues.

Authors: We agree that the explicit operator definitions and derivations were insufficiently detailed in the main text. In the revised manuscript we will provide the precise expressions for the quantized ingoing and outgoing null expansion operators on the kinematical Hilbert space, including the symmetric ordering (AE + EA)/2 chosen for the connection-triad products. We will also include the full derivation establishing essential self-adjointness on a dense domain of cylindrical functions, the construction of the generalized eigenstates, and the explicit computation of the spectrum that demonstrates the shared continuous part together with the differing isolated eigenvalues. revision: yes
Referee: [quantization procedure] Classical null-expansion expressions are products of connection A and triad E (or extrinsic curvature). Direct promotion to operators on cylindrical functions without specifying or proving invariance under ordering (e.g., EA versus AE) leaves open the possibility that different orderings yield distinct symmetric operators whose self-adjoint extensions and point spectra differ, undermining the claimed spectral structure.

Authors: We acknowledge the ordering ambiguity inherent in promoting classical products to operators. The manuscript employs a symmetric ordering to guarantee that the resulting operator is symmetric (hence admits self-adjoint extensions). In the revision we will state this choice explicitly, justify it by reference to the requirement that the operator be densely defined and symmetric on the cylindrical functions, and add a brief discussion of why alternative orderings either lead to unitarily equivalent operators or produce spectra whose continuous parts remain unchanged while only the isolated eigenvalues may shift. This preserves the central claims while clarifying the quantization procedure. revision: partial

Circularity Check

0 steps flagged

No circularity: spectra derived from direct quantization of classical expansions

full rationale

The derivation promotes classical null-expansion expressions (products involving connection and triad) to operators on the spherically symmetric LQG kinematical Hilbert space and computes their self-adjointness and spectra from the resulting operator algebra on cylindrical functions. No step reduces by construction to a fitted parameter renamed as prediction, a self-definitional loop, or a load-bearing self-citation whose content is unverified. The claimed common continuous spectrum plus differing isolated eigenvalues follows from the explicit operator action rather than from any input that already encodes the target result. External benchmarks (kinematical Hilbert space structure, standard LQG quantization) remain independent of the final spectral claims.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 0 invented entities

The central claim rests on the standard kinematical framework of spherically symmetric loop quantum gravity without introducing new free parameters or postulated entities.

axioms (1)

domain assumption Standard kinematical Hilbert space of spherically symmetric loop quantum gravity
The operators are defined and shown self-adjoint on this space as stated in the abstract.
