Performance characterisation of the Hamamatsu R760 photomultiplier tube for the PLUME detector

A. Bellavista, A. Carbone, A. Villa, F. Ferrari, L. Toscano, T. Nguyen-Trung, V. Chaumat, V. Puill

Pith reviewed 2026-05-08 13:17 UTC · model grok-4.3

classification ⚛️ physics.ins-det

keywords photomultiplier tubesR760PLUME detectorLHCb luminosityCherenkov lightgain characterisationdark currentageing behaviour

0 comments

The pith

Laboratory tests of the Hamamatsu R760 photomultiplier tubes establish operating conditions for stable luminosity measurements in the PLUME detector through LHCb Runs 3 and 4.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper performs detailed laboratory tests on the Hamamatsu R760 photomultiplier tubes installed in the PLUME luminometer at the LHCb interaction point. It quantifies absolute gain, transit-time drift, linearity, dark current, and ageing behaviour under controlled conditions. A sympathetic reader cares because these sensors must deliver consistent data on luminosity and beam conditions to support precise physics measurements over multiple years of LHC operation. If the characterisation holds, the results allow selection of voltages and settings that keep the detector stable and accurate.

Core claim

The characterisation of the Hamamatsu R760 photomultiplier tubes provides measurements of their absolute gain, transit-time drift, linearity, dark current, and ageing behaviour under controlled laboratory conditions. These results establish the operating parameters needed for the PLUME detector to monitor luminosity accurately and stably during LHCb Run 3 and Run 4.

What carries the argument

Systematic laboratory study of absolute gain, transit-time drift, linearity, dark current and ageing behaviour of the 48 Hamamatsu R760 photomultiplier tubes.

If this is right

Optimal operating conditions derived from the tests will maintain stable and precise luminosity measurements throughout Run 3 and Run 4.
The measured ageing behaviour indicates acceptable long-term degradation for the planned data-taking periods.
Linearity across expected rates and low dark current support accurate detection of Cherenkov light from charged particles.
Transit-time stability enables reliable timing information for beam-condition monitoring.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

The same characterisation approach could guide sensor choices for other beam or luminosity monitors facing comparable environmental demands.
If the lab results translate to cavern conditions, they would reduce systematic uncertainties in luminosity-normalised cross-section measurements at LHCb.
Targeted follow-up exposure of sample tubes to simulated radiation and magnetic fields could test the extrapolation from laboratory to real operating conditions.

Load-bearing premise

Laboratory conditions of temperature, humidity, light levels and absence of radiation or magnetic fields sufficiently replicate the actual operating environment inside the LHCb cavern.

What would settle it

Observation of significant unexpected gain drift, increased dark current, or timing instability when the PLUME detector operates in the actual LHCb cavern compared with the laboratory predictions.

read the original abstract

The Probe for Luminosity Measurement detector is a novel luminometer designed to monitor the luminosity and beam conditions of the Large Hadron Collider at the interaction point of the LHCb experiment, starting from Run 3. The detector is based on a hodoscope composed of 48 Hamamatsu R760 photomultiplier tubes, which detect the Cherenkov light produced by charged particles originating from the interaction region. The accurate and stable operation of these sensors is essential to ensure reliable luminosity measurements throughout the full data-taking period. This paper presents a detailed characterisation of the photomultiplier tubes currently installed in the detector. In particular, their absolute gain, transit-time drift, linearity, dark current, and ageing behaviour are systematically studied under controlled laboratory conditions. The results provide a comprehensive assessment of the performance of the detection modules and establish the optimal operating conditions required to ensure stable and precise measurements throughout Run 3 and Run 4.
