Unsupervised Learning of Quantum Phase Transitions for Bose-Hubbard lattice systems
Pith reviewed 2026-05-09 14:39 UTC · model grok-4.3
The pith
Diffusion maps applied to raw simulation snapshots can distinguish quantum phases and transitions in Bose-Hubbard lattice systems without order parameters or handcrafted features.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
An unsupervised learning approach based on diffusion maps identifies phase structure across distinct settings in bosonic lattice systems described by Bose-Hubbard type models without prior knowledge of order parameters or handcrafted observables, including ground-state transitions involving symmetry-protected topological phases and nonequilibrium regimes distinguishing ergodic and many-body localized behavior.
What carries the argument
Diffusion maps that embed high-dimensional lattice configuration snapshots into a lower-dimensional space according to their diffusion distances, thereby revealing clusters that align with physical phases.
If this is right
- The same pipeline detects ground-state transitions that involve symmetry-protected topological phases.
- Nonequilibrium dynamics can be partitioned into ergodic versus many-body localized regimes directly from the data.
- The approach requires no explicit knowledge of the Hamiltonian or choice of order parameter.
- Results obtained on classical simulations indicate the method can be applied to raw measurement records from ultracold-atom experiments.
Where Pith is reading between the lines
- Similar embedding techniques might be tested on other lattice models or higher-dimensional systems where order parameters are unknown.
- Application to real experimental data will likely require checks for robustness against shot noise and finite sampling that are not addressed in the simulations.
- If the method succeeds on noisy data, it could shorten the loop between data collection and phase identification in current quantum simulators.
Load-bearing premise
The input data snapshots from Bose-Hubbard simulations contain sufficient information for diffusion maps to separate phases without additional feature engineering or knowledge of the underlying Hamiltonian.
What would settle it
A concrete falsifier would be a collection of Bose-Hubbard snapshots from a system with a known, well-characterized phase transition that, after diffusion-map embedding and standard parameter choices, yields a single connected component with no separable clusters corresponding to the distinct phases.
Figures
read the original abstract
Characterizing quantum many-body phase structure is a major goal for quantum simulation. Here, we employ an unsupervised learning approach based on diffusion maps to learn phase transitions in bosonic lattice systems described by Bose-Hubbard type models, which can be realized in ultracold atoms and related quantum simulation platforms. We demonstrate that this approach identifies phase structure across distinct settings without prior knowledge of order parameters or handcrafted observables, including ground-state transitions involving symmetry-protected topological phases and nonequilibrium regimes distinguishing ergodic and many-body localized behavior. Our results indicate that the approach has the potential for direct application to experimentally accessible measurement data for learning quantum phases in current quantum simulators.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The paper introduces an unsupervised learning method using diffusion maps applied to raw simulation snapshots from Bose-Hubbard lattice models to identify quantum phase transitions. It demonstrates the method's ability to detect phase structures in various settings, including ground-state transitions with symmetry-protected topological phases and nonequilibrium regimes separating ergodic and many-body localized behaviors, without relying on prior knowledge of order parameters or handcrafted observables.
Significance. If the results hold, this approach could provide a valuable tool for directly analyzing experimental data from quantum simulators such as ultracold atoms, enabling phase discovery with minimal theoretical assumptions. The fixed hyperparameters across examples and alignment of embeddings with known boundaries strengthen the unsupervised claim and reproducibility.
minor comments (2)
- The description of input data preparation (local density or correlation snapshots) should explicitly state the spatial resolution and system sizes used in each example to allow readers to assess information content without additional feature engineering.
- In the results sections showing embeddings and clustering, include quantitative metrics (e.g., silhouette scores or adjusted Rand index against known boundaries) alongside visualizations to strengthen the claim of successful phase separation.
Simulated Author's Rebuttal
We thank the referee for their positive summary of our work, for highlighting its potential applicability to experimental data from quantum simulators, and for recommending minor revision. We appreciate the recognition that fixed hyperparameters and alignment with known phase boundaries support the unsupervised nature of the method.
Circularity Check
No significant circularity detected
full rationale
The paper's core procedure applies diffusion maps directly to unlabeled simulation snapshots (local densities or correlations) from Bose-Hubbard models. The resulting low-dimensional embedding and subsequent clustering are produced solely from the intrinsic geometry of the input data matrix; no phase labels, order parameters, or target quantities enter the diffusion-map construction or eigenvalue problem. Validation against known phase boundaries occurs only after the unsupervised step and serves as external consistency check rather than input to the algorithm. Hyperparameters are held fixed across examples, and no self-citations are invoked to justify uniqueness or to close the derivation. Consequently the claimed separation of ground-state and nonequilibrium phases is not equivalent to its inputs by construction.
Axiom & Free-Parameter Ledger
axioms (1)
- domain assumption Diffusion maps embed high-dimensional data according to a diffusion process that reveals underlying manifold structure corresponding to distinct phases.
Reference graph
Works this paper leans on
-
[1]
We also acknowledge the OU Supercomputing Center for Education & Research (OSCER) at the University of Oklahoma (OU), on which part of the computing for this work was performed. Appendix A: Learning many-body localization In the case of learning MBL and thermal phases, the dataset can contain large density variations in the samples space, because the samp...
-
[2]
Gross and I
C. Gross and I. Bloch, Quantum simulations with ultracold atoms in optical lattices, Science357, 995 (2017)
2017
-
[3]
Altman, K
E. Altman, K. R. Brown, G. Carleo, L. D. Carr, E. Demler, C. Chin, B. DeMarco, S. E. Economou, M. A. Eriksson, K.-M. C. Fu, M. Greiner, K. R. Hazzard, R. G. Hulet, A. J. Koll´ ar, B. L. Lev, M. D. Lukin, R. Ma, X. Mi, S. Misra, C. Monroe, K. Murch, Z. Nazario, K.-K. Ni, A. C. Potter, P. Roushan, M. Saffman, M. Schleier-Smith, I. Siddiqi, R. Simmonds, M. S...
2021
-
[4]
Bernien, S
H. Bernien, S. Schwartz, A. Keesling, H. Levine, A. Omran, H. Pichler, S. Choi, A. S. Zibrov, M. Endres, M. Greiner, et al., Probing many-body dynamics on a 51-atom quantum simulator, Nature551, 579 (2017). 9
2017
-
[5]
Bluvstein, A
D. Bluvstein, A. Omran, H. Levine, A. Keesling, G. Semeghini, S. Ebadi, T. T. Wang, A. A. Michailidis, N. Maskara, W. W. Ho,et al., Controlling quantum many-body dynamics in driven rydberg atom arrays, Science371, 1355 (2021)
2021
-
[6]
Ebadi, T
S. Ebadi, T. T. Wang, H. Levine, A. Keesling, G. Semeghini, A. Omran, D. Bluvstein, R. Samajdar, H. Pichler, W. W. Ho,et al., Quantum phases of matter on a 256-atom programmable quantum simulator, Nature595, 227 (2021)
2021
-
[7]
Semeghini, H
G. Semeghini, H. Levine, A. Keesling, S. Ebadi, T. T. Wang, D. Bluvstein, R. Verresen, H. Pichler, M. Kalinowski, R. Samajdar, A. Omran, S. Sachdev, A. Vishwanath, M. Greiner, V. Vuleti´ c, and M. D. Lukin, Probing topological spin liquids on a programmable quantum simulator, Science374, 1242 (2021)
2021
-
[8]
Manovitz, S
T. Manovitz, S. H. Li, S. Ebadi, R. Samajdar, A. A. Geim, S. J. Evered, D. Bluvstein, H. Zhou, N. U. Koyluoglu, J. Feldmeier,et al., Quantum coarsening and collective dynamics on a programmable simulator, Nature638, 86 (2025)
2025
-
[9]
E. A. Martinez, C. A. Muschik, P. Schindler, D. Nigg, A. Erhard, M. Heyl, P. Hauke, M. Dalmonte, T. Monz, P. Zoller, et al., Real-time dynamics of lattice gauge theories with a few-qubit quantum computer, Nature534, 516 (2016)
2016
-
[10]
Smith, A
J. Smith, A. Lee, P. Richerme, B. Neyenhuis, P. W. Hess, P. Hauke, M. Heyl, D. A. Huse, and C. Monroe, Many-body localization in a quantum simulator with programmable random disorder, Nature Physics12, 907 (2016)
2016
-
[11]
Zhang, G
J. Zhang, G. Pagano, P. W. Hess, A. Kyprianidis, P. Becker, H. Kaplan, A. V. Gorshkov, Z.-X. Gong, and C. Monroe, Observation of a many-body dynamical phase transition with a 53-qubit quantum simulator, Nature551, 601 (2017)
2017
-
[12]
K. J. Satzinger, Y.-J. Liu, A. Smith, C. Knapp, M. Newman, C. Jones, Z. Chen, C. Quintana, X. Mi, A. Dunsworth,et al., Realizing topologically ordered states on a quantum processor, Science374, 1237 (2021)
2021
-
[13]
T. I. Andersen, N. Astrakhantsev, A. H. Karamlou, J. Berndtsson, J. Motruk, A. Szasz, J. A. Gross, A. Schuckert, T. Westerhout, Y. Zhang,et al., Thermalization and criticality on an analogue–digital quantum simulator, Nature638, 79 (2025)
2025
-
[14]
X. Mi, M. Ippoliti, C. Quintana, A. Greene, Z. Chen, J. Gross, F. Arute, K. Arya, J. Atalaya, R. Babbush,et al., Time-crystalline eigenstate order on a quantum processor, Nature601, 531 (2022)
2022
-
[15]
Lebrat, M
M. Lebrat, M. Xu, L. H. Kendrick, A. Kale, Y. Gang, P. Seetharaman, I. Morera, E. Khatami, E. Demler, and M. Greiner, Observation of nagaoka polarons in a fermi–hubbard quantum simulator, Nature629, 317 (2024)
2024
-
[16]
L´ eonard, S
J. L´ eonard, S. Kim, J. Kwan, P. Segura, F. Grusdt, C. Repellin, N. Goldman, and M. Greiner, Realization of a fractional quantum hall state with ultracold atoms, Nature619, 495 (2023)
2023
-
[17]
M. Xu, L. H. Kendrick, A. Kale, Y. Gang, G. Ji, R. T. Scalettar, M. Lebrat, and M. Greiner, Frustration-and doping- induced magnetism in a fermi–hubbard simulator, Nature620, 971 (2023)
2023
-
[18]
M. P. A. Fisher, P. B. Weichman, G. Grinstein, and D. S. Fisher, Boson localization and the superfluid-insulator transition, Phys. Rev. B40, 546 (1989)
1989
-
[19]
Jaksch, C
D. Jaksch, C. Bruder, J. I. Cirac, C. W. Gardiner, and P. Zoller, Cold bosonic atoms in optical lattices, Phys. Rev. Lett. 81, 3108 (1998)
1998
-
[20]
Greiner, O
M. Greiner, O. Mandel, T. Esslinger, T. W. H¨ ansch, and I. Bloch, Quantum phase transition from a superfluid to a mott insulator in a gas of ultracold atoms, Nature415, 39 (2002)
2002
-
[21]
Bloch, J
I. Bloch, J. Dalibard, and W. Zwerger, Many-body physics with ultracold gases, Rev. Mod. Phys.80, 885 (2008)
2008
-
[22]
W. S. Bakr, J. I. Gillen, A. Peng, S. F¨ olling, and M. Greiner, A quantum gas microscope for detecting single atoms in a hubbard-regime optical lattice, Nature462, 74 (2009)
2009
-
[23]
J. F. Sherson, C. Weitenberg, M. Endres, M. Cheneau, I. Bloch, and S. Kuhr, Single-atom-resolved fluorescence imaging of an atomic mott insulator, Nature467, 68 (2010)
2010
-
[24]
Gross and W
C. Gross and W. S. Bakr, Quantum gas microscopy for single atom and spin detection, Nature Physics17, 1316 (2021)
2021
-
[25]
D. Wei, A. Rubio-Abadal, B. Ye, F. Machado, J. Kemp, K. Srakaew, S. Hollerith, J. Rui, S. Gopalakrishnan, N. Y. Yao, et al., Quantum gas microscopy of kardar-parisi-zhang superdiffusion, Science376, 716 (2022)
2022
-
[26]
Quantum-gas microscopy and Talbot interferometry of the Bose-glass phase
L. Koehn, C. Parsonage, C. W. Duncan, P. Kirton, A. J. Daley, T. Hilker, E. Haller, A. La Rooij, and S. Kuhr, Quantum-gas microscopy of the bose-glass phase, arXiv preprint arXiv:2504.13040 (2025)
work page internal anchor Pith review Pith/arXiv arXiv 2025
- [27]
-
[28]
R. Ma, B. Saxberg, C. Owens, N. Leung, Y. Lu, J. Simon, and D. I. Schuster, A dissipatively stabilized mott insulator of photons, Nature566, 51 (2019)
2019
-
[29]
Fitzpatrick, N
M. Fitzpatrick, N. M. Sundaresan, A. C. Y. Li, J. Koch, and A. A. Houck, Observation of a dissipative phase transition in a one-dimensional circuit qed lattice, Phys. Rev. X7, 011016 (2017)
2017
-
[30]
Zhang, E
X. Zhang, E. Kim, D. K. Mark, S. Choi, and O. Painter, A superconducting quantum simulator based on a photonic- bandgap metamaterial, Science379, 278 (2023)
2023
-
[31]
B. Du, R. Suresh, S. L´ opez, J. Cadiente, and R. Ma, Probing site-resolved current in strongly interacting superconducting circuit lattices, Phys. Rev. Lett.133, 060601 (2024)
2024
-
[32]
B. Du, Q. Guo, S. L´ opez, and R. Ma, Tunneling spectroscopy in superconducting circuit lattices, Phys. Rev. Res.7, L022038 (2025)
2025
- [33]
-
[34]
D. Wei, D. Adler, K. Srakaew, S. Agrawal, P. Weckesser, I. Bloch, and J. Zeiher, Observation of brane parity order in programmable optical lattices, Phys. Rev. X13, 021042 (2023)
2023
-
[35]
Rubio-Abadal, M
A. Rubio-Abadal, M. Ippoliti, S. Hollerith, D. Wei, J. Rui, S. L. Sondhi, V. Khemani, C. Gross, and I. Bloch, Floquet prethermalization in a bose-hubbard system, Phys. Rev. X10, 021044 (2020)
2020
-
[36]
M. Z. Hasan and C. L. Kane, Colloquium: Topological insulators, Rev. Mod. Phys.82, 3045 (2010)
2010
-
[37]
Qi and S.-C
X.-L. Qi and S.-C. Zhang, Topological insulators and superconductors, Rev. Mod. Phys.83, 1057 (2011). 10
2011
-
[38]
Lukinet al., Probing entanglement in a many-body–localized system, Science364, 256 (2019)
A. Lukinet al., Probing entanglement in a many-body–localized system, Science364, 256 (2019)
2019
-
[39]
A. M. Kaufman, M. E. Tai, A. Lukin, M. Rispoli, R. Schittko, P. M. Preiss, and M. Greiner, Quantum thermalization through entanglement in an isolated many-body system, Science353, 794 (2016)
2016
-
[40]
D. A. Abanin, E. Altman, I. Bloch, and M. Serbyn, Colloquium: Many-body localization, thermalization, and entanglement, Reviews of Modern Physics91, 021001 (2019)
2019
-
[41]
Z.-P. Cian, H. Dehghani, A. Elben, B. Vermersch, G. Zhu, M. Barkeshli, P. Zoller, and M. Hafezi, Many-body chern number from statistical correlations of randomized measurements, Phys. Rev. Lett.126, 050501 (2021)
2021
-
[42]
Elben, J
A. Elben, J. Yu, G. Zhu, M. Hafezi, F. Pollmann, P. Zoller, and B. Vermersch, Many-body topological invariants from randomized measurements in synthetic quantum matter, Science advances6, eaaz3666 (2020)
2020
-
[43]
Carrasquilla and R
J. Carrasquilla and R. G. Melko, Machine learning phases of matter, Nature Physics13, 431 (2017)
2017
-
[44]
E. P. Van Nieuwenburg, Y.-H. Liu, and S. D. Huber, Learning phase transitions by confusion, Nature Physics13, 435 (2017)
2017
-
[45]
B. S. Rem, N. K¨ aming, M. Tarnowski, L. Asteria, N. Fl¨ aschner, C. Becker, K. Sengstock, and C. Weitenberg, Identifying quantum phase transitions using artificial neural networks on experimental data, Nature Physics15, 917 (2019)
2019
-
[46]
Wang, Discovering phase transitions with unsupervised learning, Phys
L. Wang, Discovering phase transitions with unsupervised learning, Phys. Rev. B94, 195105 (2016)
2016
-
[47]
W. Hu, R. R. P. Singh, and R. T. Scalettar, Discovering phases, phase transitions, and crossovers through unsupervised machine learning: A critical examination, Phys. Rev. E95, 062122 (2017)
2017
-
[48]
S. J. Wetzel, Unsupervised learning of phase transitions: From principal component analysis to variational autoencoders, Phys. Rev. E96, 022140 (2017)
2017
-
[49]
K¨ aming, A
N. K¨ aming, A. Dawid, K. Kottmann, M. Lewenstein, K. Sengstock, A. Dauphin, and C. Weitenberg, Unsupervised machine learning of topological phase transitions from experimental data, Machine Learning: Science and Technology2, 035037 (2021)
2021
-
[50]
Ch’ng, N
K. Ch’ng, N. Vazquez, and E. Khatami, Unsupervised machine learning account of magnetic transitions in the Hubbard model, Physical Review E97, 013306 (2018)
2018
-
[51]
J. F. Rodriguez-Nieva and M. S. Scheurer, Identifying topological order through unsupervised machine learning, Nature Physics15, 790 (2019)
2019
-
[52]
Lidiak and Z
A. Lidiak and Z. Gong, Unsupervised Machine Learning of Quantum Phase Transitions Using Diffusion Maps, Physical Review Letters125, 225701 (2020)
2020
-
[53]
Y. Che, C. Gneiting, T. Liu, and F. Nori, Topological quantum phase transitions retrieved through unsupervised machine learning, Physical Review B102, 134213 (2020)
2020
-
[54]
Yu, S.-Y
L.-W. Yu, S.-Y. Zhang, P.-X. Shen, and D.-L. Deng, Unsupervised learning of interacting topological phases from experi- mental observables, Fundamental Research4, 1086 (2024)
2024
- [55]
-
[56]
Kuo and H
E.-J. Kuo and H. Dehghani, Unsupervised learning of interacting topological and symmetry-breaking phase transitions, Physical Review B105, 235136 (2022)
2022
-
[57]
Baier, M
S. Baier, M. J. Mark, D. Petter, K. Aikawa, L. Chomaz, Z. Cai, M. Baranov, P. Zoller, and F. Ferlaino, Extended Bose-Hubbard models with ultracold magnetic atoms, Science352, 201 (2016)
2016
-
[58]
Fersterer, A
P. Fersterer, A. Safavi-Naini, B. Zhu, L. Gabardos, S. Lepoutre, L. Vernac, B. Laburthe-Tolra, P. B. Blakie, and A. M. Rey, Dynamics of an itinerant spin-3 atomic dipolar gas in an optical lattice, Physical Review A100, 033609 (2019)
2019
-
[59]
L. Su, A. Douglas, M. Szurek, R. Groth, S. F. Ozturk, A. Krahn, A. H. H´ ebert, G. A. Phelps, S. Ebadi, S. Dickerson, F. Ferlaino, O. Markovi´ c, and M. Greiner, Dipolar quantum solids emerging in a Hubbard quantum simulator, Nature 622, 724 (2023)
2023
-
[60]
E. G. Dalla Torre, E. Berg, and E. Altman, Hidden Order in 1D Bose Insulators, Physical Review Letters97, 260401 (2006)
2006
-
[61]
Ejima, F
S. Ejima, F. Lange, and H. Fehske, Spectral and Entanglement Properties of the Bosonic Haldane Insulator, Physical Review Letters113, 020401 (2014)
2014
-
[62]
E. Berg, E. G. Dalla Torre, T. Giamarchi, and E. Altman, Rise and fall of hidden string order of lattice bosons, Physical Review B77, 245119 (2008)
2008
-
[63]
Rossini and R
D. Rossini and R. Fazio, Phase diagram of the extended Bose–Hubbard model, New Journal of Physics14, 065012 (2012)
2012
-
[64]
Fu, Topological Crystalline Insulators, Physical Review Letters106, 106802 (2011)
L. Fu, Topological Crystalline Insulators, Physical Review Letters106, 106802 (2011)
2011
-
[65]
T. L. Hughes, E. Prodan, and B. A. Bernevig, Inversion-symmetric topological insulators, Physical Review B83, 245132 (2011)
2011
-
[66]
A. M. Turner, Y. Zhang, and A. Vishwanath, Entanglement and inversion symmetry in topological insulators, Physical Review B82, 241102 (2010)
2010
-
[67]
Rispoli, A
M. Rispoli, A. Lukin, R. Schittko, S. Kim, M. E. Tai, J. L´ eonard, and M. Greiner, Quantum critical behaviour at the many-body localization transition, Nature573, 385 (2019)
2019
-
[68]
D. M. Basko, I. L. Aleiner, and B. L. Altshuler, Metal–insulator transition in a weakly interacting many-electron system with localized single-particle states, Annals of Physics321, 1126 (2006)
2006
-
[69]
D. A. Abanin and Z. Papi´ c, Recent progress in many-body localization, Annalen der Physik529, 1700169 (2017)
2017
-
[70]
Nandkishore and D
R. Nandkishore and D. A. Huse, Many-Body Localization and Thermalization in Quantum Statistical Mechanics, Annual Review of Condensed Matter Physics6, 15 (2015). 11
2015
-
[71]
D. A. Huse, R. Nandkishore, and V. Oganesyan, Phenomenology of fully many-body-localized systems, Physical Review B90, 174202 (2014)
2014
-
[72]
T. B. Wahl, A. Pal, and S. H. Simon, Signatures of the many-body localized regime in two dimensions, Nature Physics 15, 164 (2019)
2019
-
[73]
Alet and N
F. Alet and N. Laflorencie, Many-body localization: An introduction and selected topics, Comptes Rendus. Physique19, 498 (2018)
2018
-
[74]
Sierant and J
P. Sierant and J. Zakrzewski, Many-body localization of bosons in optical lattices, New Journal of Physics20, 043032 (2018)
2018
-
[75]
Yao and J
R. Yao and J. Zakrzewski, Many-body localization in the Bose-Hubbard model: Evidence for mobility edge, Physical Review B102, 014310 (2020)
2020
-
[76]
H. P. L¨ uschen, P. Bordia, S. Scherg, F. Alet, E. Altman, U. Schneider, and I. Bloch, Observation of Slow Dynamics near the Many-Body Localization Transition in One-Dimensional Quasiperiodic Systems, Physical Review Letters119, 260401 (2017)
2017
-
[77]
Schreiber, S
M. Schreiber, S. S. Hodgman, P. Bordia, H. P. L¨ uschen, M. H. Fischer, R. Vosk, E. Altman, U. Schneider, and I. Bloch, Observation of many-body localization of interacting fermions in a quasirandom optical lattice, Science349, 842 (2015)
2015
- [78]
-
[79]
S. S. Kondov, W. R. McGehee, W. Xu, and B. DeMarco, Disorder-Induced Localization in a Strongly Correlated Atomic Hubbard Gas, Physical Review Letters114, 083002 (2015)
2015
-
[80]
Pal and D
A. Pal and D. A. Huse, Many-body localization phase transition, Physical Review B82, 174411 (2010)
2010
