Search for K_{S(L)}⁰ rightarrow π⁺π⁻μ⁺μ⁻ decays at LHCb
Pith reviewed 2026-05-18 01:27 UTC · model grok-4.3
The pith
No signals found for neutral kaons decaying to two pions and two muons, yielding the first upper limits on these branching fractions.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
No KS0 or KL0 signals are observed in the reconstructed pi+ pi- mu+ mu- final state, resulting in branching fraction upper limits of less than 1.4 times 10 to the minus 9 for the short-lived neutral kaon and less than 6.6 times 10 to the minus 7 for the long-lived neutral kaon, both at 90 percent confidence level.
What carries the argument
Reconstruction and selection of pi+ pi- mu+ mu- candidates from LHCb proton-proton collision data, followed by fitting the invariant mass distribution to separate any potential signal from combinatorial and physical backgrounds.
If this is right
- The branching fraction for KS0 to pi+ pi- mu+ mu- must lie below 1.4 times 10 to the minus 9.
- The branching fraction for KL0 to pi+ pi- mu+ mu- must lie below 6.6 times 10 to the minus 7.
- These processes occur at rates too low to be observed with the current integrated luminosity of 5.4 inverse femtobarns.
Where Pith is reading between the lines
- Future larger datasets could tighten these limits or reveal the decays if their rates approach the current bounds.
- The limits provide a benchmark for theoretical calculations of rare kaon processes involving both hadronic and leptonic final states.
- Similar search techniques could be applied to related rare decays involving different lepton combinations or additional particles.
Load-bearing premise
Background modeling, signal efficiency, and systematic uncertainties in the detector response and selection are accurately estimated and do not conceal a small signal.
What would settle it
A statistically significant excess of events at the kaon mass in the invariant mass spectrum of selected candidates, either in additional LHCb data or in an independent experiment, would contradict the reported upper limits.
Figures
read the original abstract
A search for $K_{\mathrm{S(L)}}^{0} \rightarrow \pi^{+}\pi^{-}\mu^{+}\mu^{-}$ decays is performed using proton-proton collision data collected by the LHCb experiment at a centre-of-mass energy of $13\,\mathrm{TeV}$, corresponding to an integrated luminosity of $5.4\,\mathrm{fb^{-1}}$. No $K_{\mathrm{S(L)}}^{0} \rightarrow \pi^{+}\pi^{-}\mu^{+}\mu^{-}$ signals are found and upper limits are set for the first time on the branching fractions $\mathcal{B}(K_\text{S}^{0} \rightarrow \pi^{+}\pi^{-}\mu^{+}\mu^{-}) < 1.4 \times 10^{-9}$ and $\mathcal{B}(K_\text{L}^{0} \rightarrow \pi^{+}\pi^{-}\mu^{+}\mu^{-}) < 6.6 \times 10^{-7}$, at the 90% confidence level.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The manuscript reports a search for the rare decays KS0 → π+π−μ+μ− and KL0 → π+π−μ+μ− performed with 5.4 fb−1 of 13 TeV proton-proton collision data collected by the LHCb experiment. No signals are observed, and the first upper limits on the branching fractions are set at the 90% confidence level: B(KS0 → π+π−μ+μ−) < 1.4 × 10−9 and B(KL0 → π+π−μ+μ−) < 6.6 × 10−7.
Significance. If the background estimation, signal efficiency (accounting for the large lifetime difference between KS and KL), and systematic uncertainties are correctly evaluated, this constitutes the first experimental constraints on these branching fractions. The result is valuable for rare kaon physics, as it can be compared against Standard Model expectations and used to limit possible new-physics contributions. The analysis employs standard LHCb techniques for displaced-vertex reconstruction and particle identification, with no reported internal inconsistencies.
minor comments (2)
- The abstract provides no information on background modeling or efficiency determination; while the full text presumably contains these details, a brief sentence summarizing the method would improve accessibility for readers who only see the abstract.
- Figure captions and table headings should explicitly state the integrated luminosity and center-of-mass energy to allow quick cross-reference with the data sample description in §2.
Simulated Author's Rebuttal
We thank the referee for the positive review and the recommendation to accept the manuscript. The referee's summary accurately describes our search for the rare decays and the resulting upper limits.
Circularity Check
No significant circularity; data-driven null result with standard limit setting
full rationale
The paper reports a search for rare KS0 and KL0 decays in 5.4 fb^{-1} of LHCb pp collision data at 13 TeV. No signals are observed, and 90% CL upper limits on the branching fractions are set directly from the data. Background estimation uses sideband or simulation methods, signal efficiencies are determined from Monte Carlo samples tuned to data, and limits follow conventional statistical procedures (e.g., CLs or profile likelihood). No equation or step reduces by construction to a fitted parameter or self-citation; prior LHCb references on detector response are external calibration inputs, not load-bearing for the null observation. The derivation chain is self-contained and falsifiable against the collision dataset.
Axiom & Free-Parameter Ledger
axioms (1)
- domain assumption Standard Model predicts branching fractions well below the sensitivity of the current dataset.
Reference graph
Works this paper leans on
-
[1]
Closing in on the radiative weak chiral couplings
L. Cappiello, O. Cat` a, and G. D’Ambrosio,Closing in on the radiative weak chiral couplings, Eur. Phys. J.C78(2018) 265,arXiv:1712.10270
work page internal anchor Pith review Pith/arXiv arXiv 2018
-
[2]
L. M. Sehgal and M. Wanninger,CP violation in the decay K 0 L →π +π−e+e−, Phys. Rev.D46(1992) 1035, Erratum ibid.D46(1992) 5209
work page 1992
-
[3]
Laiet al.,Investigation of K 0 L,S →π +π−e+e− decays, Eur
NA48 collaboration, A. Laiet al.,Investigation of K 0 L,S →π +π−e+e− decays, Eur. Phys. J.C30(2003) 33
work page 2003
-
[4]
NA48/1 collaboration, J. R. Batleyet al.,Precision measurement of the ratio BR(KS →π +π−e+e−)/BR(KL →π +π−π0 D), Phys. Lett.B694(2011) 301
work page 2011
-
[5]
P. Heiliger and L. M. Sehgal,Direct and indirect CP violation in the decay KL →π +π−e+e−, Phys. Rev.D48(1993) 4146, Erratum ibid.D60(1999) 079902
work page 1993
-
[6]
K->pipie+e- decays and chiral low-energy constants
H. Pichl, K→ππe +e− decays and chiral low-energy constants, Eur. Phys. J.C20 (2001) 371,arXiv:hep-ph/0010284. 9
work page internal anchor Pith review Pith/arXiv arXiv 2001
- [7]
-
[8]
Aaijet al.,Constraints on the K 0 S →µ +µ− branching fraction, Phys
LHCb collaboration, R. Aaijet al.,Constraints on the K 0 S →µ +µ− branching fraction, Phys. Rev. Lett.125(2020) 1231801,arXiv:2001.10354
-
[9]
Aaijet al.,Search for K 0 S(L) →µ +µ−µ+µ− decays at LHCb, Phys
LHCb collaboration, R. Aaijet al.,Search for K 0 S(L) →µ +µ−µ+µ− decays at LHCb, Phys. Rev.D108(2023) L031102,arXiv:2212.04977
-
[10]
Navaset al.,Review of particle physics, Phys
Particle Data Group, S. Navaset al.,Review of particle physics, Phys. Rev.D110 (2024) 030001
work page 2024
-
[11]
LHCb collaboration, A. A. Alves Jr.et al.,The LHCb detector at the LHC, JINST3 (2008) S08005
work page 2008
-
[12]
LHCb collaboration, R. Aaijet al.,LHCb detector performance, Int. J. Mod. Phys. A30(2015) 1530022,arXiv:1412.6352
work page internal anchor Pith review Pith/arXiv arXiv 2015
-
[13]
Performance of the LHCb Vertex Locator
R. Aaijet al.,Performance of the LHCb Vertex Locator, JINST9(2014) P09007, arXiv:1405.7808
work page internal anchor Pith review Pith/arXiv arXiv 2014
-
[14]
Improved performance of the LHCb Outer Tracker in LHC Run 2
P. d’Argentet al.,Improved performance of the LHCb Outer Tracker in LHC Run 2, JINST12(2017) P11016,arXiv:1708.00819
work page internal anchor Pith review Pith/arXiv arXiv 2017
-
[15]
Performance of the LHCb RICH detector at the LHC
M. Adinolfiet al.,Performance of the LHCb RICH detector at the LHC, Eur. Phys. J.C73(2013) 2431,arXiv:1211.6759
work page internal anchor Pith review Pith/arXiv arXiv 2013
-
[16]
A. A. Alves Jr.et al.,Performance of the LHCb muon system, JINST8(2013) P02022,arXiv:1211.1346
work page internal anchor Pith review Pith/arXiv arXiv 2013
-
[17]
The LHCb Trigger and its Performance in 2011
R. Aaijet al.,The LHCb trigger and its performance in 2011, JINST8(2013) P04022, arXiv:1211.3055
work page internal anchor Pith review Pith/arXiv arXiv 2011
-
[18]
R. Aaijet al.,Optimization of the muon reconstruction algorithms for LHCb Run 2, LHCb-PUB-2017-007, 2017
work page 2017
-
[19]
F. Dettori, D. Martinez Santos, and J. Prisciandaro,Low- pT dimuon triggers at LHCb in Run 2, LHCb-PUB-2017-023, 2017
work page 2017
-
[20]
The LHCb Stripping Project: Sustainable Legacy Data Processing for High-Energy Physics
N. Grieseret al.,The LHCb stripping project: Sustainable legacy data processing for high-energy physics,arXiv:2509.05294
work page internal anchor Pith review arXiv
-
[21]
A Brief Introduction to PYTHIA 8.1
T. Sj¨ ostrand, S. Mrenna, and P. Skands,A brief introduction to PYTHIA 8.1, Comput. Phys. Commun.178(2008) 852,arXiv:0710.3820
work page internal anchor Pith review Pith/arXiv arXiv 2008
-
[22]
T. Sj¨ ostrand, S. Mrenna, and P. Skands,PYTHIA 6.4 physics and manual, JHEP05 (2006) 026,arXiv:hep-ph/0603175
work page internal anchor Pith review Pith/arXiv arXiv 2006
-
[23]
I. Belyaevet al.,Handling of the generation of primary events in Gauss, the LHCb simulation framework, J. Phys. Conf. Ser.331(2011) 032047
work page 2011
-
[24]
D. J. Lange,The EvtGen particle decay simulation package, Nucl. Instrum. Meth. A462(2001) 152. 10
work page 2001
-
[25]
PHOTOS Interface in C++; Technical and Physics Documentation
N. Davidson, T. Przedzinski, and Z. Was,PHOTOS interface in C++: Technical and physics documentation, Comput. Phys. Commun.199(2016) 86, arXiv:1011.0937
work page internal anchor Pith review Pith/arXiv arXiv 2016
-
[26]
Allisonet al.,Geant4 developments and applications, IEEE Trans
Geant4 collaboration, J. Allisonet al.,Geant4 developments and applications, IEEE Trans. Nucl. Sci.53(2006) 270
work page 2006
-
[27]
Agostinelliet al.,Geant4: A simulation toolkit, Nucl
Geant4 collaboration, S. Agostinelliet al.,Geant4: A simulation toolkit, Nucl. Instrum. Meth.A506(2003) 250
work page 2003
-
[28]
Clemencicet al.,The LHCb simulation application, Gauss: Design, evolution and experience, J
M. Clemencicet al.,The LHCb simulation application, Gauss: Design, evolution and experience, J. Phys. Conf. Ser.331(2011) 032023
work page 2011
-
[29]
L. Breiman, J. H. Friedman, R. A. Olshen, and C. J. Stone,Classification and regression trees, Wadsworth international group, Belmont, California, USA, 1984
work page 1984
-
[30]
Y. Freund and R. E. Schapire,A decision-theoretic generalization of on-line learning and an application to boosting, J. Comput. Syst. Sci.55(1997) 119
work page 1997
-
[31]
XGBoost: A Scalable Tree Boosting System
T. Chen and C. Guestrin,XGBoost: A scalable tree boosting system, inProceedings of the 22nd ACM SIGKDD International Conference on Knowledge Discovery and Data Mining, KDD ’16, (New York, NY, USA), 785–794, ACM, 2016, arXiv:1603.02754
work page internal anchor Pith review Pith/arXiv arXiv 2016
-
[32]
Mapping the material in the LHCb vertex locator using secondary hadronic interactions
M. Alexanderet al.,Mapping the material in the LHCb vertex locator using secondary hadronic interactions, JINST13(2018) P06008,arXiv:1803.07466
work page internal anchor Pith review Pith/arXiv arXiv 2018
-
[33]
Scikit-learn: Machine Learning in Python
F. Pedregosaet al.,Scikit-learn: Machine learning in Python, J. Mach. Learn. Res.12 (2011) 2825, arXiv:1201.0490, and online at http://scikit-learn.org/stable/
work page internal anchor Pith review Pith/arXiv arXiv 2011
-
[34]
T. Skwarnicki,A study of the radiative cascade transitions between the Upsilon-prime and Upsilon resonances, PhD thesis, Institute of Nuclear Physics, Krakow, 1986, DESY-F31-86-02
work page 1986
-
[35]
J. Podolanski and R. Armenteros,Analysis of V-events, The London, Edinburgh, and Dublin Philosophical Magazine and Journal of Science45(1954) 13
work page 1954
-
[36]
Measurement of the track reconstruction efficiency at LHCb
LHCb collaboration, R. Aaijet al.,Measurement of the track reconstruction efficiency at LHCb, JINST10(2015) P02007,arXiv:1408.1251
work page internal anchor Pith review Pith/arXiv arXiv 2015
-
[37]
Measurement of the KL meson lifetime with the KLOE detector
KLOE collaboration, F. Ambrosinoet al.,Measurement of the KL meson lifetime with the KLOE detector, Phys. Lett.B626(2005) 15,arXiv:hep-ex/0507088
work page internal anchor Pith review Pith/arXiv arXiv 2005
-
[38]
KLOE collaboration, F. Ambrosinoet al.,Measurements of the absolute branching ratios for the dominant KL decays, the KL lifetime, and Vus with the KLOE detector, Phys. Lett.B632(2006) 43,arXiv:hep-ex/0508027
work page internal anchor Pith review Pith/arXiv arXiv 2006
-
[39]
KLOE-2 collaboration, D. Babusciet al.,Measurement of the branching fraction for the decay KS →πµν with the KLOE detector, Phys. Lett.B804(2020) 135378, arXiv:1912.05990. 11 LHCb collaboration R. Aaij38 , A.S.W. Abdelmotteleb 58 , C. Abellan Beteta 52 , F. Abudin´ en58 , T. Ackernley62 , A. A. Adefisoye 70 , B. Adeva48 , M. Adinolfi 56 , P. Adlarson86 , C...
