arxiv: 2604.10445 · v1 · submitted 2026-04-12 · 💻 cs.PL

Recognition: unknown

Points-to Analysis Using MDE: A Multi-level Deduplication Engine for Repetitive Data and Operations

Aditi Raste, Anamitra Ghorui, Uday P. Khedker

Authors on Pith no claims yet

Pith reviewed 2026-05-10 16:23 UTC · model grok-4.3

classification 💻 cs.PL

keywords pointer analysispoints-to analysisdeduplicationmemory optimizationcontext-sensitive analysisflow-sensitive analysisdata redundancyperformance scaling

0 comments

The pith

A recursive multi-level deduplication engine cuts memory use up to 18x and runtime 8x in flow- and context-sensitive pointer analysis.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

Pointer analysis repeatedly performs the same set operations and propagates duplicate data, wasting most of its effort. Measurements show over 90 percent of set-union operations can be redundant. The paper introduces a Multi-level Deduplication Engine that builds unique representations recursively from other deduplicated values and memoizes operations. This turns repeated work into constant-time lookups. When integrated into an existing pointer analysis, the approach delivers large reductions in peak memory and runtime that increase with larger input programs.

Core claim

The authors establish that a Multi-level Deduplication Engine recursively augments data representations through de-duplication and assignment of unique identifiers, allowing many low-level operations to be trivialized or memoized while capturing structural redundancy that non-recursive methods miss, thereby scaling precise flow- and context-sensitive pointer analysis without loss of information.

What carries the argument

Multi-level Deduplication Engine (MDE), a recursive mechanism that de-duplicates values, assigns unique identifiers, and enables operation trivialization and memoization.

If this is right

Precise pointer analysis can handle substantially larger programs without precision or soundness trade-offs.
Representation choices become a primary lever for scaling analyses that involve heavy data propagation.
Performance gains grow as program size increases, favoring use on real-world codebases.
MDE can be added as a drop-in C++ library to existing analysis frameworks.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

The same recursive deduplication pattern could apply to other static analyses that repeatedly combine sets or propagate data.
Analysis frameworks might benefit from built-in support for detecting and exploiting such redundancy automatically.
Deeper structural similarities across different analysis domains could be captured by extending the recursion levels.

Load-bearing premise

The high rate of redundant set-union operations observed on SPEC benchmarks is representative of pointer analysis workloads in general, and the deduplication process introduces no precision loss or soundness issues.

What would settle it

Running the same flow- and context-sensitive pointer analysis implementation on the same SPEC benchmarks both with and without MDE integration, then checking whether the reported memory and runtime reductions appear and whether the computed points-to sets remain identical.

read the original abstract

Precise pointer analysis is a foundational component of many client analyses and optimizations. Scaling flow- and context-sensitive pointer analysis has been a long-standing challenge, suffering from combinatorial growth in both memory usage and runtime. Existing approaches address this primarily by reducing the amount of information tracked often, at the cost of precision and soundness. In our experience a significant proportion of this cost comes from propagation of duplicate data and low-level data structure operations being repeated a large number of times. Our measurements on SPEC benchmarks show that more than 90% of all set-union operations performed can be redundant. We present Multi-level Deduplication Engine (MDE), a mechanism that recursively augments the representation of data through de-duplication and the assignment of unique identifiers to values to eliminate redundancy. This allows MDE to trivialize many operations, and memoize operations enabling their future reuse. MDE's recursive structure allows it to represent de-duplicated values that themselves are constructed from other de-deuplicated values, capturing structural redundancy not easily possible with non-recursive techniques. We provide a full C++ implementation of MDE as a library and integrate it into an existing implementation of a flow- and context-sensitive pointer analysis. Evaluation on selected SPEC benchmarks shows a reduction up to 18.10x in peak memory usage and 8.15x in runtime. More notably, MDE exhibits an upward trend of effectiveness with the increase in benchmark size. Besides performance improvements, this work highlights the importance of representation design and suggests new opportunities for bringing efficiency to future analyses.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

MDE gives a recursive dedup trick for points-to sets that cuts memory and time on SPEC with bigger gains on larger programs, but the paper still needs to show the final results match the original analysis exactly.

read the letter

The punchline is that this work takes the known redundancy in set operations during pointer analysis and attacks it with a recursive multi-level deduplication engine that assigns unique IDs and memoizes results. On selected SPEC benchmarks they see more than 90 percent of unions become trivial, delivering up to 18x lower peak memory and 8x faster runs, and the savings grow with program size. That scaling observation is useful because pointer analysis pain is worst on big codebases. They ship a complete C++ library and plug it into a real flow- and context-sensitive implementation, which is concrete engineering that others can actually try. The recursive structure is the part that feels new; it lets deduplicated values contain other deduplicated values, something flat memoization usually misses. The implementation detail and the trend with benchmark size are the strongest parts of the paper. The soft spot is the missing check that the transformed sets produce identical points-to results. The abstract and evaluation focus only on speed and memory; there is no reported comparison of final sets, no equivalence test, and no argument that the ID assignment and memoization cannot change propagation order or reachability in some client analysis. Without that, the performance numbers are interesting but not yet convincing for soundness-critical use. Measurement methodology for the 90 percent figure and the speedups is also thin. This paper is for people who build or tune static analyses and care about data-structure cost inside them. A reader who needs practical ways to shrink memory in dataflow problems will get concrete ideas and numbers to build on. It deserves a serious referee because the core mechanism is new in this setting and the empirical results are specific enough to review, even if the soundness gap needs to be closed in revision.

Referee Report

2 major / 2 minor

Summary. The paper introduces the Multi-level Deduplication Engine (MDE), a recursive mechanism that augments data representations in points-to analysis via deduplication and unique identifier assignment to eliminate redundancy in set-union operations and enable memoization. It reports that over 90% of set-union operations are redundant on SPEC benchmarks and claims that integrating MDE into a flow- and context-sensitive pointer analysis yields up to 18.10x peak memory reduction and 8.15x runtime improvement, with effectiveness increasing for larger benchmarks.

Significance. If the integration preserves exact points-to results, MDE offers a valuable alternative to precision-reducing approximations for scaling pointer analysis by targeting structural and operational redundancy. The provision of a complete C++ library implementation strengthens reproducibility and potential reuse in other analyses.

major comments (2)

[Evaluation] The evaluation reports concrete speedups and memory reductions but provides no comparison of final points-to sets, no output-equivalence testing, and no argument that unique-identifier assignment plus recursive deduplication leaves propagation behavior unchanged. This equivalence is load-bearing for the central claim that MDE can be integrated without affecting analysis soundness or precision.
[Abstract] The claim that more than 90% of set-union operations are redundant is presented without details on measurement methodology (e.g., how operations were instrumented or counted across client analyses), making it impossible to assess whether the figure is representative or reproducible.

minor comments (2)

[Evaluation] The upward trend of effectiveness with benchmark size is asserted but not supported by a table or figure showing per-benchmark sizes, speedups, and memory reductions.
[Evaluation] No error bars, variance across runs, or details on the SPEC benchmark selection and configuration are provided for the reported 18.10x and 8.15x factors.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the detailed and constructive comments on our manuscript. We address each of the major comments below and indicate the revisions we will make to improve the paper.

read point-by-point responses

Referee: [Evaluation] The evaluation reports concrete speedups and memory reductions but provides no comparison of final points-to sets, no output-equivalence testing, and no argument that unique-identifier assignment plus recursive deduplication leaves propagation behavior unchanged. This equivalence is load-bearing for the central claim that MDE can be integrated without affecting analysis soundness or precision.

Authors: We agree that providing evidence for semantic equivalence is essential to support our claims. Although the MDE library is designed to provide equivalent set operations through canonical representations and memoized unions that compute the same results, we did not include explicit verification in the submitted manuscript. In the revised version, we will add both a theoretical argument explaining why the recursive deduplication and unique identifier assignment preserve the exact behavior of the original set-union and propagation (as MDE acts as a drop-in replacement for the data structures without altering their semantics), and empirical results comparing the final points-to sets produced with and without MDE to confirm they are identical. We will also report any minor differences if they arise due to implementation details. revision: yes
Referee: [Abstract] The claim that more than 90% of set-union operations are redundant is presented without details on measurement methodology (e.g., how operations were instrumented or counted across client analyses), making it impossible to assess whether the figure is representative or reproducible.

Authors: The referee is correct that the measurement methodology for the 90% redundancy figure is not detailed in the abstract or the provided summary. In the full manuscript, we describe the instrumentation, but to address this, we will revise the abstract and add a dedicated subsection in the evaluation or methodology section detailing how the set-union operations were counted, including the specific client analyses used, the instrumentation approach, and the benchmarks. This will enhance reproducibility and allow assessment of representativeness. revision: yes

Circularity Check

0 steps flagged

No circularity; empirical performance claims rest on external benchmarks and implementation, not self-referential definitions or fitted predictions

full rationale

The paper describes a new MDE mechanism for deduplicating data structures in pointer analysis, provides a C++ library implementation, integrates it into an existing flow- and context-sensitive analysis, and reports measured speedups and memory reductions on SPEC benchmarks. No equations, first-principles derivations, or 'predictions' appear in the provided text. The central claims are empirical measurements of redundancy (>90% redundant set-unions) and resulting performance gains (up to 18.10x memory, 8.15x runtime). These quantities are obtained from direct execution on external benchmarks rather than being defined in terms of themselves or obtained by fitting parameters to a subset and renaming the fit as a prediction. Potential concerns about output equivalence or precision preservation are correctness issues outside the scope of circularity analysis; they do not reduce any claimed derivation to its own inputs by construction. No self-citation load-bearing steps, uniqueness theorems, or ansatzes are invoked.

Axiom & Free-Parameter Ledger

0 free parameters · 0 axioms · 0 invented entities

The abstract provides no explicit free parameters, axioms, or invented entities beyond the MDE technique itself; the central claim rests on the empirical observation of redundancy and the engineering integration of the library.
