Optimal Design and Analytical Modeling of a Soft Fin-Ray Effect Gripper Finger Using the Finite Rigid Elements Method

Sara Adeli , Hassan Sayyaadi This is my paper

Pith reviewed 2026-06-28 09:32 UTC · model grok-4.3

classification 💻 cs.RO
keywords soft roboticsfin ray effectgripper fingerfinite rigid elements methoddesign optimizationdeformation modelingagricultural grasping
0
0 comments X

The pith

A soft Fin Ray gripper finger with 30 mm length, seven ribs at -15 degrees, 10 mm spacing and 1 mm thickness allows the finite rigid elements method to predict deformation within 3 percent error.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper sets out to create an analytical model and optimal geometry for a soft gripper finger that can grasp delicate items such as tomatoes while supporting later development of force control. It applies the finite rigid elements method to simplify the nonlinear, high-degree-of-freedom behavior of soft materials into a usable analytical form. The design is refined against four performance measures and then checked by both simulation and physical tests. A reader would care because the result supplies a concrete starting point for building controllable soft grippers that avoid damage to fragile objects.

Core claim

The research establishes that the optimal finger configuration of 30 mm length, 10 mm rib spacing, seven ribs angled at -15 degrees, and 1 mm rib thickness, when modeled with the finite rigid elements method, predicts finger deformation with 3 percent error relative to experiment, while a corresponding ANSYS numerical model reaches 2 percent error.

What carries the argument

The Finite Rigid Elements Method (FREM), which breaks the soft finger into rigid segments joined by compliant connections to produce an analytical approximation of large nonlinear deflections.

If this is right

  • The selected geometry meets the four stated criteria and therefore supports gentle grasping of irregular produce.
  • The 3 percent modeling error supplies a usable foundation for building an analytical force controller.
  • The ANSYS model at 2 percent error confirms that the analytical approach is close enough for preliminary design work.
  • The same rib parameters can be used directly in fabrication without further geometric search.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • The approach could be tested on other soft materials or rib counts to see whether the same error levels appear.
  • Adding contact sensors to the optimized finger would allow closed-loop force control in real agricultural settings.
  • The rib-angle and spacing choices might transfer to non-gripper soft mechanisms such as compliant arms or adaptive surfaces.

Load-bearing premise

The four optimization criteria of tip displacement, total deflection, stress distribution, and contact force are sufficient to define performance and the finite rigid elements method accurately represents the soft material nonlinearity.

What would settle it

Fabricate the optimal finger, apply a known load at the tip, and measure the actual tip displacement; if the observed error relative to the FREM prediction exceeds 3 percent, the modeling claim does not hold.

read the original abstract

Fin Ray-inspired soft grippers offer a promising solution for gently handling delicate, irregular objects, especially in agriculture. The objective of this research is to design, fabricate, and model a Fin Ray Effect (FRE) soft gripper finger to enable precise force control in future applications. This design aims to gently grasp delicate agricultural products, such as tomatoes, that require both adaptability and accurate force application. To address the inherent challenges of soft robotics, including nonlinear behavior, infinite degrees of freedom, and variable material properties, the Finite Rigid Elements Method (FREM) was employed for modeling. This method preserves analytical accuracy while providing a reliable foundation for the development of a force controller in later stages. A detailed Finite Element Model (FEM) was created using ANSYS, and the analytical results were validated through simulation and experimental testing. The gripper's fingers were optimized based on four key criteria: tip displacement, total deflection, stress distribution, and contact force. The optimal finger configuration includes a length of 30 mm, rib spacing of 10 mm, seven ribs angled at -15 deg, and a rib thickness of 1 mm. Theoretical modeling using the FREM predicted finger deformation with a 3% error, while the ANSYS numerical model achieved 2% error.
