An analytic formula for surface currents generating prescribed plasma equilibrium fields

Wadim Gerner

Authors on Pith no claims yet

Pith reviewed 2026-05-09 22:56 UTC · model grok-4.3

classification ⚛️ physics.plasm-ph math-phmath.APmath.MP

keywords plasma equilibriumsurface currentsanalytic formulaBiot-Savart operatorcoil winding surfacenormal magnetic curvatureplasma domainmagnetic field generation

0 comments

The pith

An analytic formula gives the surface current on a coil surface that exactly reproduces any prescribed plasma equilibrium field inside the enclosed volume when added to the plasma's own contribution.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper supplies a closed-form expression that takes a plasma domain, an equilibrium magnetic field defined inside it, and an enclosing coil winding surface, then returns the surface current distribution needed on that surface. The resulting currents produce a magnetic field that, together with the field generated by the plasma current density, equals the target equilibrium field at every point inside the plasma. A reader would care because the formula replaces iterative numerical searches for coil shapes with a direct calculation and simultaneously accounts for the tendency of current density to concentrate where the plasma boundary has the greatest normal magnetic curvature.

Core claim

Given a plasma domain P, an equilibrium field B on P, and a surrounding coil surface Σ, an analytic formula exists whose output is a surface current j on Σ such that the Biot-Savart field of j plus the Biot-Savart field of curl(B) equals B everywhere inside P.

What carries the argument

The analytic formula for the surface current j on Σ, which is constructed so that its Biot-Savart integral exactly cancels the difference between B and the Biot-Savart integral of the plasma current density curl(B) throughout the interior of P.

Load-bearing premise

A suitable coil winding surface Σ surrounding the plasma domain P exists and the Biot-Savart operator applied to the surface current and to curl(B) can be combined analytically to recover B exactly inside P.

What would settle it

Evaluate the Biot-Savart integral of the formula-derived j at an interior test point and verify whether it equals B minus the Biot-Savart integral of curl(B) at that point; any measurable discrepancy falsifies the formula.

read the original abstract

Given a plasma domain $P\subset\mathbb{R}^3$, a plasma equilibrium field $B$ on $P$ and a coil winding surface $\Sigma$ surrounding $P$, we provide an analytic formula whose output is a surface current distribution $j$ on $\Sigma$ such that $\operatorname{BS}(j)+\operatorname{BS}(\operatorname{curl}(B))=B$ in $P$, i.e. the combination of the plasma current magnetic field and the surface current magnetic field exactly produce the full plasma equilibrium field. We use this new formula to provide a theoretical explanation of the empirical phenomenon that currents tend to attain their maximal strength at points which correspond to points of highest normal magnetic curvature on the plasma boundary. Some discussions regarding aspects of numerical approximations are also included.
