VeriLLMed: Interactive Visual Debugging of Medical Large Language Models with Knowledge Graphs

Haipeng Zeng, Huamin Qu, Rui Sheng, Xingyi Mao, Yanna Lin, Yurui Xiang, Yushi Sun, Yuyang Wu, Zelin Zang, Zixin Chen

Pith reviewed 2026-05-08 08:00 UTC · model grok-4.3

classification 💻 cs.CL cs.HC
keywords medical large language modelsknowledge graphsvisual analyticsdiagnostic reasoningerror detectiondebugging toolsbiomedical AIreasoning paths
0
0 comments X

The pith

VeriLLMed converts medical LLM outputs into reasoning paths and compares them against biomedical knowledge graph references to expose three classes of diagnostic errors.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

Medical LLMs can produce diagnostic outputs that look plausible but contain clinically unreliable reasoning steps, yet developers struggle to inspect them at scale without domain expertise. The paper presents VeriLLMed as a visual system that turns model responses into structured paths, builds matching reference paths from external knowledge graphs, and flags mismatches. It isolates three recurring error types: incorrect relations between concepts, wrong branching in the reasoning tree, and entirely omitted necessary steps. Case studies and expert reviews indicate that this approach surfaces implausible chains and points to concrete model fixes. A sympathetic reader would care because reliable medical AI requires catching such failures before deployment affects patient decisions.

Core claim

VeriLLMed transforms model outputs into comparable reasoning paths, constructs knowledge graph-grounded reference paths, and identifies three recurring classes of diagnosis errors: relation errors, branch errors, and missing errors. Case studies and expert evaluation demonstrate that VeriLLMed helps developers identify clinically implausible reasoning and generate actionable insights that can inform the improvement of medical LLMs.

What carries the argument

The VeriLLMed visual analytics system that converts LLM diagnostic outputs into reasoning paths and aligns them with biomedical knowledge graph reference paths to classify errors.

If this is right

  • Developers gain a way to move from isolated manual reviews to pattern-based inspection across many cases.
  • Three specific error categories become visible targets for model retraining or prompt engineering.
  • Insights from the system can directly guide iterative improvements to medical LLMs before they reach clinical use.
  • Prioritization of which failures to fix first becomes possible when recurring patterns are quantified.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • The same path-comparison approach could be adapted to debug LLMs in other high-stakes fields such as legal reasoning or financial forecasting.
  • Keeping the reference knowledge graphs current would require ongoing maintenance pipelines as medical knowledge evolves.
  • The three error classes might serve as labels for new training objectives that penalize relation, branch, and missing mistakes explicitly.

Load-bearing premise

The selected biomedical knowledge graphs supply accurate, complete, and current reference paths that correctly represent proper diagnostic reasoning in the tested cases.

What would settle it

An independent panel of clinicians reviewing the same model outputs could find that the errors flagged by VeriLLMed do not match actual clinical implausibility or that the reference paths themselves contain inaccuracies.

Figures

Figures reproduced from arXiv: 2604.23356 by Haipeng Zeng, Huamin Qu, Rui Sheng, Xingyi Mao, Yanna Lin, Yurui Xiang, Yushi Sun, Yuyang Wu, Zelin Zang, Zixin Chen.

Figure 1
Figure 1. Figure 1: The user interface of VeriLLMed. (A) Dataset Overview summarizes the distribution of reasoning errors and overall model accuracy. (B) Projection View localizes erroneous concept regions in the Bio-KG embedding space. (C) Path View compares aggregated local reasoning structures around selected entities. (D) Error View summarizes recurrent erroneous reasoning and their corresponding reference reasoning. (E) … view at source ↗
Figure 2
Figure 2. Figure 2: The pipeline of data processing and component extraction. Given a medical QA case, the diagnosis model first predicts the answer together view at source ↗
Figure 3
Figure 3. Figure 3: (A) The glyph design of the Path View, based on the Bio-KG embedding space. Node positions indicate their connections in the KG. (B) We also considered a matrix-based alternative, where each cell represents a transition from a row entity to a column entity and contains a similar glyph summarizing path participation and error composition. structures around selected entities and identify which nodes warrant … view at source ↗
Figure 4
Figure 4. Figure 4: (A) Our design uses a comparative Sankey layout to summarize view at source ↗
read the original abstract

Large language models (LLMs) show promise in medical diagnosis, but real-world deployment remains challenging due to high-stakes clinical decisions and imperfect reasoning reliability. As a result, careful inspection of model behavior is essential for assessing whether diagnostic reasoning is reliable and clinically grounded. However, debugging medical LLMs remains difficult. First, developers often lack sufficient medical domain expertise to interpret model errors in clinically meaningful terms. Second, models can fail across a large and diverse set of instances involving different input types, tasks, and reasoning steps, making it challenging for developers to prioritize which errors deserve focused inspection. Third, developers struggle to identify recurring error patterns across cases, as existing debugging practices are largely instance-centric and rely on manual inspection of isolated failures. To address these challenges, we present VeriLLMed, a visual analytics system that integrates external biomedical knowledge to audit and debug medical LLM diagnostic reasoning. VeriLLMed transforms model outputs into comparable reasoning paths, constructs knowledge graph-grounded reference paths, and identifies three recurring classes of diagnosis errors: relation errors, branch errors, and missing errors. Case studies and expert evaluation demonstrate that VeriLLMed helps developers identify clinically implausible reasoning and generate actionable insights that can inform the improvement of medical LLMs.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

2 major / 2 minor

Summary. The paper presents VeriLLMed, a visual analytics system that integrates biomedical knowledge graphs to audit medical LLM diagnostic reasoning. It transforms model outputs into comparable reasoning paths, constructs KG-grounded reference paths, classifies errors into relation errors, branch errors, and missing errors, and uses interactive visualizations to help developers identify recurring patterns. Case studies and expert evaluation are offered as evidence that the system enables identification of clinically implausible reasoning and generation of actionable insights for LLM improvement.

Significance. If the KG reference paths reliably proxy correct clinical reasoning, VeriLLMed could meaningfully address the three stated challenges (domain expertise gaps, error prioritization across instances, and pattern detection) by providing a structured, visual debugging workflow for medical LLMs. The error taxonomy and visual interface represent a practical contribution to LLM auditing tools, though the absence of quantitative validation metrics limits the strength of the supporting evidence.

major comments (2)
  1. [System overview and error classification (sections describing reference path construction and error taxonomy)] The central claim that VeriLLMed identifies 'clinically implausible reasoning' rests on the assumption that the chosen biomedical KGs yield reference paths that accurately and completely encode correct diagnostic reasoning. No quantitative comparison of KG-derived paths against independent clinician-annotated paths, no coverage statistics for the evaluated cases, and no sensitivity analysis for KG incompleteness or outdated relations are provided; this makes the error classifications (relation/branch/missing) difficult to interpret as clinically grounded rather than KG-specific artifacts.
  2. [Case studies and expert evaluation] The evaluation relies on case studies and expert evaluation to support claims of actionable insights and identification of implausible reasoning, yet reports no quantitative metrics (e.g., inter-rater agreement, task completion times, error detection rates), participant numbers, study design details, or controls. This leaves the strength of evidence for the central usability and insight-generation claims unclear.
minor comments (2)
  1. [Abstract] The abstract and introduction would benefit from a brief statement of the number of cases, experts, and KGs used in the evaluation to allow readers to gauge scope immediately.
  2. [Figures and visualizations] Ensure all figures include clear legends, axis labels, and direct references in the text; some visual elements may require additional annotation to distinguish model paths from reference paths at a glance.

Simulated Author's Rebuttal

2 responses · 1 unresolved

We thank the referee for the constructive and detailed feedback on our manuscript. The comments highlight important aspects of grounding our error classifications and strengthening the evaluation evidence. We address each major comment point-by-point below, indicating planned revisions where they align with the manuscript's scope. We believe these changes will clarify the claims without overstating the current evidence.

read point-by-point responses

  1. Referee: [System overview and error classification (sections describing reference path construction and error taxonomy)] The central claim that VeriLLMed identifies 'clinically implausible reasoning' rests on the assumption that the chosen biomedical KGs yield reference paths that accurately and completely encode correct diagnostic reasoning. No quantitative comparison of KG-derived paths against independent clinician-annotated paths, no coverage statistics for the evaluated cases, and no sensitivity analysis for KG incompleteness or outdated relations are provided; this makes the error classifications (relation/branch/missing) difficult to interpret as clinically grounded rather than KG-specific artifacts.

    Authors: We agree that the fidelity of KG-derived reference paths as proxies for correct clinical reasoning is a foundational assumption, and that the absence of quantitative validation metrics makes it harder to interpret the error classifications as fully clinically grounded. The manuscript (Section 3.2) constructs reference paths from established biomedical KGs and defines the three error classes explicitly as deviations from these paths; the case studies then illustrate how these deviations surface implausible steps. The expert evaluation provides qualitative confirmation that experts viewed the flagged errors as clinically relevant. However, we did not include coverage statistics, sensitivity analysis, or direct comparisons to independent clinician annotations in the original submission. In the revised version, we will add a new limitations subsection in the Discussion that reports coverage statistics for the evaluated cases (derived from the KG) and discusses potential impacts of KG incompleteness. We will also explicitly scope the claims to 'KG-grounded' rather than claiming absolute clinical correctness. A full quantitative clinician-annotation study lies beyond the current work's resources and is noted as future work. revision: partial

  2. Referee: [Case studies and expert evaluation] The evaluation relies on case studies and expert evaluation to support claims of actionable insights and identification of implausible reasoning, yet reports no quantitative metrics (e.g., inter-rater agreement, task completion times, error detection rates), participant numbers, study design details, or controls. This leaves the strength of evidence for the central usability and insight-generation claims unclear.

    Authors: We acknowledge that the Evaluation section would benefit from greater transparency on study details to better support the claims of actionable insights. The manuscript presents two detailed case studies showing how the visual interface reveals recurring error patterns, followed by expert evaluation in which domain experts interacted with the system to audit LLM outputs and generate improvement suggestions. To strengthen this, we will revise the section to specify the number of expert participants, the semi-structured interview protocol used, and any observed consistency in the insights generated. While the original study did not collect quantitative metrics such as inter-rater agreement or task completion times (focusing instead on qualitative demonstration of the workflow), we will add an explicit statement of this scope and note that controlled quantitative usability testing remains valuable future work. These additions will make the evidence base clearer without changing the qualitative nature of the reported findings. revision: partial

standing simulated objections not resolved
  • A full quantitative validation comparing KG-derived paths against independent clinician-annotated reference paths would require new data collection and annotation effort that is not feasible within the timeline or scope of this revision.

Circularity Check

0 steps flagged

No significant circularity; system design validated externally

full rationale

The paper describes a visual analytics system (VeriLLMed) that transforms LLM outputs into reasoning paths, builds reference paths from external biomedical KGs, and classifies errors into relation/branch/missing types. Central claims rest on case studies and expert evaluation demonstrating utility for identifying implausible reasoning. No mathematical derivations, equations, fitted parameters, or predictions appear in the text. No self-citations serve as load-bearing uniqueness theorems, and no ansatzes or renamings reduce the result to its inputs by construction. The KG reference paths and expert judgments function as external benchmarks, keeping the evaluation self-contained and non-circular.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 1 invented entities

The work is a system-building paper rather than a derivation; it relies on the domain assumption that biomedical knowledge graphs can serve as ground truth and introduces the three error classes as a new categorization scheme.

axioms (1)
  • domain assumption Biomedical knowledge graphs provide reliable reference paths for correct diagnostic reasoning.
    Invoked when constructing reference paths to compare against model outputs.
invented entities (1)
  • Relation errors, branch errors, and missing errors no independent evidence
    purpose: To classify recurring patterns of flawed diagnostic reasoning in medical LLMs.
    These three categories are defined by the paper based on the system's analysis of model outputs.
