· Lean TheoremMathVista: Evaluating Mathematical Reasoning of Foundation Models in Visual Contexts
Pith reviewed 2026-05-11 01:25 UTC · model grok-4.3
The pith
MathVista benchmark shows the top foundation model reaches only 49.9 percent accuracy on visual mathematical reasoning tasks.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
MathVista is a benchmark of 6,141 examples that merges challenges from 28 prior multimodal datasets with three newly created ones (IQTest, FunctionQA, PaperQA) to test fine-grained visual understanding together with compositional mathematical reasoning. Evaluation of twelve foundation models shows GPT-4V attaining 49.9 percent overall accuracy, outperforming Bard by 15.1 points, while still trailing humans by 10.4 points because it struggles to parse intricate figures and to carry out rigorous step-by-step reasoning.
What carries the argument
The MathVista benchmark, which unifies existing and new visual-math tasks to quantify combined perception and reasoning in foundation models.
If this is right
- GPT-4V's lead stems mainly from stronger visual perception and mathematical reasoning than other models.
- Self-verification and self-consistency methods can raise accuracy on these tasks.
- Interactive chatbot use of GPT-4V shows promise for handling visually rich math problems.
- The remaining gap to human performance highlights the need for better joint vision-and-reasoning capabilities in future models.
Where Pith is reading between the lines
- Benchmarks like this may accelerate targeted training data that pairs diagrams with explicit reasoning chains.
- Models passing MathVista could still fail on dynamic scenes or real-time visual math not captured in static images.
- The performance ordering among models may shift if new architectures emphasize diagram parsing before symbolic manipulation.
Load-bearing premise
The 6,141 selected examples form a representative sample of the mathematical reasoning problems that appear in visual settings.
What would settle it
A collection of visual mathematics problems drawn independently of the 28 source datasets on which GPT-4V scores near human levels while still scoring 50 percent on MathVista would undermine the benchmark's claimed representativeness.
read the original abstract
Large Language Models (LLMs) and Large Multimodal Models (LMMs) exhibit impressive problem-solving skills in many tasks and domains, but their ability in mathematical reasoning in visual contexts has not been systematically studied. To bridge this gap, we present MathVista, a benchmark designed to combine challenges from diverse mathematical and visual tasks. It consists of 6,141 examples, derived from 28 existing multimodal datasets involving mathematics and 3 newly created datasets (i.e., IQTest, FunctionQA, and PaperQA). Completing these tasks requires fine-grained, deep visual understanding and compositional reasoning, which all state-of-the-art foundation models find challenging. With MathVista, we have conducted a comprehensive, quantitative evaluation of 12 prominent foundation models. The best-performing GPT-4V model achieves an overall accuracy of 49.9%, substantially outperforming Bard, the second-best performer, by 15.1%. Our in-depth analysis reveals that the superiority of GPT-4V is mainly attributed to its enhanced visual perception and mathematical reasoning. However, GPT-4V still falls short of human performance by 10.4%, as it often struggles to understand complex figures and perform rigorous reasoning. This significant gap underscores the critical role that MathVista will play in the development of general-purpose AI agents capable of tackling mathematically intensive and visually rich real-world tasks. We further explore the new ability of self-verification, the application of self-consistency, and the interactive chatbot capabilities of GPT-4V, highlighting its promising potential for future research. The project is available at https://mathvista.github.io/.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The paper introduces MathVista, a benchmark for mathematical reasoning in visual contexts that aggregates 6,141 examples from 28 existing multimodal datasets plus three newly authored ones (IQTest, FunctionQA, PaperQA). It reports a comprehensive evaluation of 12 foundation models, with GPT-4V achieving the highest overall accuracy of 49.9% (15.1 points above Bard) while remaining 10.4 points below human performance. The work further examines GPT-4V's self-verification, self-consistency, and interactive capabilities, and releases the benchmark publicly.
Significance. If the benchmark proves representative, MathVista supplies a much-needed quantitative yardstick for multimodal models on tasks that combine fine-grained visual perception with compositional mathematical reasoning. The public release of the 6,141-example suite, together with the systematic comparison of 12 models, provides a reproducible baseline that can guide future model development. The observed gap between GPT-4V and both weaker models and humans underscores the value of such targeted benchmarks.
major comments (2)
- [§3] §3 (Dataset Construction): The paper supplies only high-level descriptions of the three newly created datasets (IQTest, FunctionQA, PaperQA). No quantitative diversity statistics, pre-registered inclusion criteria, inter-annotator agreement figures, or explicit filtering rules are reported. Because the headline result (GPT-4V at 49.9 % vs. Bard at ~34.8 %) rests on the claim that these 6,141 examples constitute an unbiased sample of visual mathematical reasoning, the absence of these details is load-bearing for interpreting the 15.1-point margin.
- [§4.2] §4.2 (Evaluation Protocol): The scoring procedure for open-ended and free-form answers is not fully specified (e.g., exact matching rules, use of LLM judges, handling of partial credit). Ambiguities here could systematically affect accuracy numbers across models and thereby the reported performance gaps.
minor comments (2)
- [Table 1] Table 1 and Figure 2: The breakdown of example counts and task categories across the 28 existing datasets plus the three new ones would benefit from an explicit column showing the proportion of each source that survived filtering.
- [Abstract] Abstract: The sentence stating that GPT-4V 'falls short of human performance by 10.4%' should be accompanied by a brief parenthetical on how human accuracy was measured (number of annotators, time limits, etc.).
Simulated Author's Rebuttal
We thank the referee for the constructive feedback and the recommendation of minor revision. We appreciate the emphasis on improving the transparency of dataset construction and evaluation details, which will strengthen the paper. We address each major comment below and describe the planned revisions.
read point-by-point responses
-
Referee: [§3] §3 (Dataset Construction): The paper supplies only high-level descriptions of the three newly created datasets (IQTest, FunctionQA, PaperQA). No quantitative diversity statistics, pre-registered inclusion criteria, inter-annotator agreement figures, or explicit filtering rules are reported. Because the headline result (GPT-4V at 49.9 % vs. Bard at ~34.8 %) rests on the claim that these 6,141 examples constitute an unbiased sample of visual mathematical reasoning, the absence of these details is load-bearing for interpreting the 15.1-point margin.
Authors: We acknowledge that Section 3 currently offers primarily high-level descriptions of IQTest, FunctionQA, and PaperQA. In the revised manuscript we will expand this section with quantitative diversity statistics (e.g., topic distributions across algebra, geometry, and statistics; counts of visual complexity levels) and explicit statements of the inclusion criteria and filtering rules applied during curation. Because these three datasets were created internally by the author team without a pre-registered protocol or multiple independent annotators, inter-annotator agreement figures are not available and cannot be supplied. We will add a brief limitations paragraph clarifying this point and its implications for claims of representativeness. revision: partial
-
Referee: [§4.2] §4.2 (Evaluation Protocol): The scoring procedure for open-ended and free-form answers is not fully specified (e.g., exact matching rules, use of LLM judges, handling of partial credit). Ambiguities here could systematically affect accuracy numbers across models and thereby the reported performance gaps.
Authors: We agree that the current description of the scoring protocol in §4.2 leaves room for ambiguity. In the revised version we will provide a detailed specification of the exact matching rules (including normalization steps for units, formatting, and synonyms), confirm that no LLM judges were used for the main results (scoring relied on rule-based matching supplemented by human verification for edge cases), and clarify the policy on partial credit and multiple valid answers. These additions will improve reproducibility and allow readers to better assess the reported gaps, such as the 15.1-point margin between GPT-4V and Bard. revision: yes
Circularity Check
No circularity: direct empirical evaluation on assembled benchmark
full rationale
The paper constructs MathVista by merging 28 existing multimodal math datasets with three newly authored ones (IQTest, FunctionQA, PaperQA) and then reports model accuracies obtained by direct, independent inference on the resulting 6,141 examples. No equations, fitted parameters, or first-principles derivations appear; the headline numbers (GPT-4V at 49.9 %) are raw test-set measurements, not quantities that reduce to the curation process by construction. Self-citations to prior datasets are ordinary sourcing and do not bear the load of any claimed prediction or uniqueness theorem. The evaluation chain is therefore self-contained against external benchmarks and exhibits none of the enumerated circularity patterns.
Axiom & Free-Parameter Ledger
axioms (1)
- domain assumption Completing these tasks requires fine-grained, deep visual understanding and compositional reasoning.
